SBC84820 Pentium
IDE Primary/Secondary Master/Slave UDMA
Ultra DMA 66/100 implementation is possible only if your IDE hard drive
supports it and the operating environment includes a DMA driver
(Windows 95 OSR2 or a third-party IDE bus master driver). If your hard
drive and your system software support Ultra DMA 33/66/100, select Auto
to enable BIOS support. The options available are Auto, Mode 0, Mode 1,
and Mode 2.
On-Chip Primary/Secondary PCI IDE
The integrated peripheral controller contains an IDE interface with
support for two IDE channels. Select Enabled to activate each channel
separately. The default value is "Enabled" .
NOTE:
Choosing Disabled for these options will
automatically remove the IDE Primary
Master/Slave PIO and/or IDE Secondary
Master/Slave PIO items on the menu.
USB Keyboard Support
Select Enabled if your system contains a Universal Serial Bus (USB)
controller and you have a USB keyboard.
Init Display First
This item allows you to decide to active whether PCI Slot or AGP first.
The options available are PCI Slot, AGP.
IDE HDD Block Mode
This field allows your hard disk controller to use the fast block mode to
transfer data to and from your hard disk drive.
POWER ON Function
This option allows users to select the type of power ON sequence for the
system to follow. The default value is "Button-Only" .
Award BIOS Utility
®
M All-in-One Capa Board User's Manual
49
