SBC84820 Pentium M All-in-One Capa Board User's Manual
Video Off Method
Determines the manner in which the monitor is blanked.
V/H
SYNC+Blank
DPMS
Blank Screen
Video Off After
As the system moves from lesser to greater power-saving modes, select
the mode in which you want the monitor to blank off. The default value is
"Standby" .
NA
Suspend
Standby
Doze
NOTE:
Green monitors detect the V/H SYNC signals to turn off its
electron gun
Modem Use IRQ
3, 4, 5, 7,
9, 10, 11,
NA
Doze Mode
After the selected period of system inactivity (1 minute to 1 hour), the
CPU clock runs at slower speed while all other devices still operate at full
speed. The default value is "Disabled" .
Disabled
1/2/4/6/8/10/20/30/
40 Min/1 Hr
54
Turns OFF vertical and horizontal
synchronization ports and writes blanks to the
video buffer
Select this option if your monitor supports the
Display Power Management Signaling (DPMS)
standard of the Video Electronics Standards
Association (VESA). Use the software supplied
for your video subsystem to select video power
management values.
System only writes blanks to the video buffer.
System BIOS will never turn off the screen
Screen off when system is in SUSPEND mode
Screen off when system is in STANDBY mode
Screen off when system is in DOZE mode
For external modem, 3 or 4 will be used for card
type modem. It is up to card definition. Default is
3.
System will never enter doze mode
Defines the continuous idle time before
the system entering DOZE mode.
Award BIOS Utility
