SBC84820 Pentium

M All-in-One Capa Board User's Manual

C h a p t e r 4

The Phoenix-Award BIOS has a built-in Setup program that

allows users to modify the basic system configuration. This

type of information is stored in a battery-backed RAM (CMOS

RAM) that retains the Setup information each time the power is

turned off.

4.1

There are two ways to enter the Setup program. You may

either turn ON the computer and press <Del> immediately, or

press the <Del> and/or <Ctrl>, <Alt>, and <Esc> keys

simultaneously when the following message appears at the

bottom of the screen during POST (Power on Self Test).

TO ENTER SETUP PRESS DEL KEY

If the message disappears before you respond and you still

wish to enter Setup, restart the system and try again. This is

possible by turning the system power to OFF then to ON,

pressing the "RESET" button on the system case, or by

simultaneously pressing <Ctrl>, <Alt>, and <Del> keys. If you

do not press the keys at the correct time and the system does

not boot, an error message will be displayed and you will be

prompted with the following:

Award BIOS Utility
