SBC84820 Pentium M All-in-One Capa Board User's Manual
CN6: Hirose DF-20 40 pin connector
Pin Deception
1 VCCM
3 VCCM
5 VCCM
7 NC
9 GND
11 LVDSB_D3-
13 LVDSB_D3+
15 GND
17 LVDSB_CLK-
19 LVDSB_CLK+
21 GND
23 LVDSA_D0-
25 LVDSA_D0+
27 GND
29 LVDSA_D1-
31 LVDSA_D1+
33 GND
35 LVDSA_D2-
37 LVDSA_D2+
39 GND
CN8: Hirose Connector for Inverter
PIN Description
1 +12V
+12V
2
3 VCC
BKLT_EN
4
5 GND
GND
6
7 GND
20
Pin Deception
2 VCCM
4 VCCM
6 VCCM
8 NC
10 GND
12 LVDSB_D0-
14 LVDSB_D0+
16 GND
18 LVDSB_D1-
20 LVDSB_D1+
22 GND
24 LVDSB_D2-
26 LVDSB_D2+
28 GND
30 LVDSA_D3-
32 LVDSA_D3+
34 GND
36 LVDSA_CLK-
38 LVDSA_CLK+
40 GND
Hardware Description
