SBC84820 Pentium

M All-in-One Capa Board User's Manual

CN10: RJ-45 Connector Pin Assignment

TX+ (Data transmission positive

TX- (Data transmission negative)

Rx+(Data reception positive)

RJ45 termination

Rx- (Data reception negative)

RJ45 termination

Signal

Hardware Description

1 2 3 4 5 6 7 8

RJ-45
