SBC84820 Pentium M All-in-One Capa Board User's Manual
Onboard Multi I/O:
One floppy port supporting up to one devices (LS-120
or ZIP Bootable)
One SPP/EPP/ECP parallel port with 26-pin 2.0 pitch
box-header ; supports LS-120
Two 16550 UART-compatible serial ports with
+5V/+12V power output in Pin 1 or Pin 9 via DIP jumper
setting.
1 x RS-232
1 x RS-232/422/485 and selectable via jumper setting
and auto flow control supported
COM3/4 are optional
USB Interface:
Real Time Clock:
Watchdog Timer:
255 levels as SMI and Reset from 0~255 seconds
controlled by W83627HG
Board Unique ID:
Dallas DS2401 board unique ID supported for
customized application
Hardware Monitoring:
Integrate Winbond W83627HG Super I/O.
Monitoring for CPU/System temperatures,
System Voltage and Chassis/CPU Fan speeds
Graphics/Streaming:
VGA On-chip Intel
Supports up to 2048x1536 at 60 Hz resolution on non-
interlaced CRT minitors
Optional Dual LVDS LCD via Chrontel CH7308A
transmitter on the AX93208 stacking board
LCD backlight control supported
18Bits or 36Bits LVDS LCD interface.
4
4 USB ports with fuse protection and
complies with USB Spec. Rev. 2.0
Integrate Intel
®
®
915GM
ICH6M
Introduction
