SBC84820 Pentium M All-in-One Capa Board User's Manual
System BIOS Cacheable
Selecting Enabled allows caching of the system BIOS ROM at F0000h-
FFFFFh, resulting in better system performance. However, if any
program writes to this memory area, a system error may result. The
default value is "Disabled" .
Video BIOS Cacheable
This item allows you to change the Video BIOS location from ROM to
RAM. Video Shadow will increase the video speed.
Video RAM Cacheable
Selecting Enabled allows caching of the video BIOS ROM at C0000h to
C7FFFh, resulting in better video performance. However, if any program
writes to this memory area, a system error may result. The default value
is "Disabled" .
Memory Hole at 15M-16M
You can reserve this area of system memory for ISA adapter ROM.
When this area is reserved, it cannot be cached. The user information of
peripherals that need to use this area of system memory usually
discusses their memory requirements. The default value is "Disabled" .
Delayed Transaction
The chipset has an embedded 32-bit posted write buffer to support delay
transactions cycles. Select Enabled to support compliance with PCI
specification version 2.1. The options available are Enabled and Disabled .
AGP Aperture Size (MB)
The field sets aperture size of the graphics. The aperture is a portion of
the PCI memory address range dedicated for graphics memory address
space. Host cycles that hit the aperture range are forwarded to the AGP
without any translation. The options available are 4M, 8M, 16M, 32M,
64M, 128M and 256M.
Award BIOS Utility
46
