2. Position Baxter's arm approximately 20cm above the landmark, with the
landmark centered in the camera's display.
Baxter should recognize the landmark and highlight it with a green outline.
If Baxter cannot locate the landmark, as in the example below, do one of the following:
• make sure the camera is 20cm above the landmark.
• adjust the gain to make the image brighter or darker.
• move the landmark module so that it's closer to the center of the camera's point
of view.
• remove the end effector.
