MEOLink User Manual
Mm1SiteEntry
mm1SiteIdIndex
mm1SiteType
mm1SiteCtrlIpAddress
mm1SiteAcmOp
mm1SiteAcmDefaultModCod
mm1SiteAcmEsNoMargin
mm1SiteAcmEsNoHysteresis
mm1SiteAcmReportEsNoOp
mm1SiteAupcOp
mm1SiteAupcEsNoMargin
mm1SiteAupcEsNoHysteresis mm1HundredthdB
}
mm1SiteIdIndex OBJECT-TYPE
SYNTAX mm1ModemSite
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"The Site ID Index."
::= { mm1SiteEntry 1 }
mm1SiteType OBJECT-TYPE
SYNTAX INTEGER { notused(0), remote(1) }
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The Site Type: remote or not used."
::= { mm1SiteEntry
mm1SiteCtrlIpAddr OBJECT-TYPE
SYNTAX IpAddress
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The Site control plane IP address.
should be set to 127.0.0.1.
mm1CtrlInterfaceConfig control plane IP Address."
::= { mm1SiteEntry
mm1SiteAcmOp OBJECT-TYPE
SYNTAX INTEGER { off(0), on(1) }
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Adaptive Coding and Modulation (ACM) operational state."
::= { mm1SiteEntry
mm1SiteAcmDefaultModCod OBJECT-TYPE
SYNTAX mm1ModemModCod
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The Site default DVB-S2 ModCod.
::= { mm1SiteEntry
mm1SiteAcmEsNoMargin OBJECT-TYPE
SYNTAX mm1HundredthdB (25..200)
UNITS "dBm"
MAX-ACCESS read-write
STATUS current
DESCRIPTION
Rev 002vx
1141780,
::= SEQUENCE {
mm1ModemSite,
INTEGER,
IpAddress,
INTEGER,
INTEGER,
mm1HundredthdB,
mm1HundredthdB,
INTEGER,
INTEGER,
mm1HundredthdB,
2 }
The value is overridden by the
3 }
4 }
5 }
For the local site, the IP address
ModCod of 0 is not a valid selection."
