MEOLink User Manual


Field
MODCOD Mask Properties
Modulation Codes


3.2.5.4 AUPC
Advanced Uplink Power Control (AUPC) conserves satellite power through outbound carrier
attenuation adjustments based on Es/No and link utilization.  When link utilization is low and
link conditions are favorable, AUPC adds attenuation to reduce the transmit power.  When
link utilization increases or link conditions become less favorable, attenuation is reduced to
increase the transmit power. When full capacity is reached, AUPC applies zero attenuation
and  the  MEOLink  modem  operates  at  the  fully  configured  transmit  power  level,  a  setting
that presumably contains sufficient margin to provide the desired level of service.
It is desirable to have the update interval of AUPC much slower than that of ACM so that as
power  changes,  the  ACM  algorithm  has  an  opportunity  to  run  and  change  ModCods,  thus
enhancing the effect of AUPC to settle into the configured utilization range.
The  AUPC  algorithm  monitors  the  received  Es/No  levels  of  the  terminals  to  which  it
transmits,  as  well  as  the  link  utilization  to  determine  the  best  power  adjustments.  The
operator  may  configure  the  AUPC  parameters  specified  in  Table  7  to  customize  the
algorithm.
Enabling and configuring AUPC requires two steps:
 Rev 002vx
1141780,


Figure 29: ACM Configuration Screen
1. From  the  Configuration  tab,  select  AUPC.  From  this  screen,  configure  the  AUPC
parameters  with  appropriate  values;  see  Figure  30.    Fortunately,  AUPC  can
generally be operated  with default values.


Definition/Configuration
Checked modcodes are available to be used by
the system





3‐25
