MEOLink User Manual
2.1.1.2 Modem Flash Installation via FTP
For FTP site setup (no TFTP Server), load release files (example is for release 03.00.05) into
the MEOLink modem as follows:
2.1.2 MEOLink Modem Operator Login and Main Menu
Use this information to connect to the modem initially. To change these values, follow the
steps below.
Rev 002vx
1141780,
2. To update the Modem Flash with the newly installed files on the boot server, follow
the procedure described in 2.1.3 and 2.1.3.1
1. Load the files from your PC, Laptop or other computer to the MEOLink modem
using FTP follows
a. ftp <modem‐ip‐address>
b. Name: o3b
c. password: o3b
d. ftp> pas
e. ftp> bin
f. ftp> put o3b‐03.00.05.tar.bz2
g. ftp>put o3bboot‐03.00.05.tar.bz2
h. ftp>quit
2. To update the Modem Flash with the newly installed files on the boot server,
follow the procedure described in 2.1.3 and 2.1.3.1 Section 2.1.3.2
1. Log into the modem via Telnet using the modem's default IP address
(192.168.2.177)
2. Enter user name operator and password o3bo3b and press enter. The public license
information and main User Menu appear.
8. rfcal (directory for custom calibration files)
9. u‐boot.bin
Figure 5: Telnet Login
2‐9
