Field
Demod A Summary
PL Sync State
Radial Es/No
Equalization Err
Demod B Summary
PL Sync State
Radial Es/No
Equalization Err
The equalization filter diagnostic shows the complex coefficients that are currently being used by the
adaptive equalizer for each demodulator. These coefficients are for factory support reference and should
be ignored by the operator.
3‐56
MEOLink User Manual
Definition/Configuration
DemodA PL sync state
DemodA radial Es/No (dB)
DemodA equalization error
DemodB PL sync state
DemodB radial Es/No (dB)
DemodB equalization error
