MEOLink User Manual
LED
TEST Loopback is on or TX
test signal such as
AWGN, CW
PWR (Fan 1) Power present to
Fan1
FAULT (Fan 1) Fan 1 speed does not
match the set speed
(+/‐ 20%)
PWR (Fan 2) Power present to
Fan2
FAULT (Fan 2) Fan 2 speed does not
match the set speed
(+/‐ 20%)
PWR (Fan 3) Power present to
Fan3
FAULT (Fan 3) Fan 3 speed does not
match the set speed
(+/‐ 20%)
1.1.5 MEOLink Modem Physical/Environmental Guidelines
Table 3 provides the physical and temperature guidelines for the MEOLink Modem.
Size
Weight
MTBF
Dimensions
Ambient Operating Temperature
Ambient Non‐operating and storage temperature
Ambient operating humidity (Non‐condensing)
Non‐Operating Humidity (Non‐condensing)
Rev 002vx
1141780,
On Off
Not TX test signal
and not in loopback
No power present to
Fan1
Fan 1 is present and
passes the speed
check
No power present to
Fan2
Fan 2 is present and
passes the speed
check
No power present to
Fan3
Fan 3 is present and
passes the speed
check
Table 3: Physical and Temperature Guidelines
Condition
Flashing
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
Specification
EIA Standard Rack Mount 2 RU
22 lbs
45,000 Hours
See Figure 3
Minimum: (15° C) ° F
Maximum: (40° C) ° F
Minimum: (‐20° C) ° F
Maximum: (70° C) ° F
20 to 90%
up to 95%
Slow Blink
1‐5
