ViaSat MEOLink User Manual page 20

2.1.4 MEOLink Modem Network Configuration in EEPROM
The default network configuration values from the factory are (also note Section 2.1.6 ‐
Restoring Factory Defaults):
Use this information to connect to the modem initially. To change these values, follow the
steps below; Figure 9 through Figure 15 illustrate the steps.
2‐12
a. IP Address: 192.168.2.177
b. Netmask: 255.255.255.0
c. Gateway IP: 192.168.2.1
d. TFTP Server IP: 192.168.2.171
1. Enter e to enter the eeprom configuration.
2. Enter h to change the hostname (ModemName can be up to 15 characters long;
e.g., use "o3btSN" where the SN is the last two digits of the serial number. For
example, o3bt40.). When prompted to change, enter y to enter the new name.
NOTE: For all the steps that follow, the procedure is similar to changing the
hostname: i.e., when prompted whether you want to change the value, enter y,
then enter the new value.
3. Enter t to change the TFTP boot server address.
4. Enter i to change the modem's control port IP address. Note: Control Interface is
IPv4 only.
5. Enter n to change the modem netmask IP address.
6. Enter g to change the gateway address to the address of the switch or router IP
address.
7. Enter k to return to the main menu, and then enter r to reboot the modem.
