MEOLink User Manual
Field
Date Plane Interface
Preferred Data Plane
VLAN Lo Id
Force Data Plane
Control Plane Interface
IP Address
IP Subnet Mask
IP Gateway
Ethernet Bonding State
TFTP IP Address
FPGA Filename
Linux Filename
Modem Tar Filename
NTP IP Address
SNMP Trap Address
SNMP R-O Community
SNMP R-W Community
3.2.5.8 Test
The Test configuration is used to set the desired loopback mode (IF, Ethernet, and Satellite).
Note: the AWGN Noise Level field is for future use and will be functional in a future
software release.
Field
Test
IF Loopback Operation
IF Loop Demod
Sat Loopback Operation
Eth Loopback Operation
Test Command Operation
AWGN Noise Level
Test Pattern
Rev 002vx
1141780,
Definition/Configuration
Select Primary or Secondary
Determines threshold for directing packets to either Data Plane A or B
Force the Preferred Data Plane selection (ignores the VLAN Lo Id threshold
value)
Control plane IP Address
Control plane subnet mask
Control plane IP gateway address
Enable/Disable control plane Ethernet interface bonding
Control plane TFTP server IP address
TFTP server host FPGA image filename
TFTP server Linux image filename
TFTP server TAR image filename
NTP server IP address. Change requires a modem reboot to take effect
SNMP Trap (inform) server IP address
SNMP read-only community name
SNMP read-write community name
Table 11: Test Configuration Parameters
Definition/Configuration
Enable/Disable IF loopback operation
Select DemodA or DemodB for IF
loopback
Modem satellite loopback mode.
Cannot be enabled with IF loopback
Modem Ethernet loopback mode.
Cannot be enabled with IF loopback
Reserved for future use.
Reserved for future use.
Reserved for future use.
3‐31
