"Modem satellite loopback mode.
::= { mm1TestConfig
mm1EthLoopbackOp OBJECT-TYPE
SYNTAX INTEGER { off(0), on(1) }
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Modem Ethernet loopback mode.
::= { mm1TestConfig
mm1TestCommandOp OBJECT-TYPE
SYNTAX INTEGER { off(0), on(1) }
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Reserved for future use.
Must be set to on for mm1AwgnNoiseLevel and mm1TestPattern to work."
::= { mm1TestConfig
mm1AwgnNoiseLevel OBJECT-TYPE
SYNTAX INTEGER
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Reserved for future use.
Requires testCommandOp to be on."
::= { mm1TestConfig
mm1TestPattern OBJECT-TYPE
SYNTAX INTEGER { none(0), cw(1) }
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Reserved for future use.
Requires testCommandOp to be on."
::= { mm1TestConfig
--
-- Modem Site Configuration Table
--
mm1SiteTable OBJECT-TYPE
SYNTAX SEQUENCE OF Mm1SiteEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"A configuration table containing the modem specific information
for the corresponding site ID index."
::= { mm1SiteConfig
mm1SiteEntry OBJECT-TYPE
SYNTAX Mm1SiteEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing modem site configuration parameters."
INDEX { mm1SiteIdIndex }
::= { mm1SiteTable 1 }
7‐82
Cannot be enabled with IF loopback."
3 }
Cannot be enabled with IF loopback."
4 }
Test command operational state.
5 }
AWGN noise level for test purposes.
6 }
Test pattern for test purposes.
7 }
1 }
