MEOLink User Manual
"DemodB Q tap value for the corresponding tap index."
::= { mm1DemodConstellationBufferEntry
--
-- Waveform Demodulator Diagnostics Table
--
mm1WfDemodDiagnosticsTable OBJECT-TYPE
SYNTAX SEQUENCE OF Mm1WfDemodDiagnosticsEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"A table containing demodulator diagnostics information per
Waveform ID."
::= { mm1DemodDiagnostics 9 }
mm1WfDemodDiagnosticsEntry OBJECT-TYPE
SYNTAX Mm1WfDemodDiagnosticsEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing demodulator diagnostics for a given Waveform ID."
INDEX { mm1WfDemodDiagnosticsWaveformIndex }
::= { mm1WfDemodDiagnosticsTable
Mm1WfDemodDiagnosticsEntry ::= SEQUENCE {
mm1WfDemodDiagnosticsWaveformIndex
mm1WfDemodulatorDiagModCodId
mm1WfDemodAFrameCnt
mm1WfDemodAEsNoDropFrameCnt
mm1WfDemodAFreqOffsetDropFrameCnt
mm1WfDemodAOtherDropFrameCnt
mm1WfDemodBFrameCnt
mm1WfDemodBEsNoDropFrameCnt
mm1WfDemodBFreqOffsetDropFrameCnt
mm1WfDemodBOtherDropFrameCnt
}
mm1WfDemodDiagnosticsWaveformIndex OBJECT-TYPE
SYNTAX mm1ModemWaveform
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Waveform index for each table entry.
for this table."
::= { mm1WfDemodDiagnosticsEntry
mm1WfDemodulatorModCodId OBJECT-TYPE
SYNTAX mm1ModemModCod
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"ModCod ID for each table entry."
::= { mm1WfDemodDiagnosticsEntry
mm1WfDemodAFrameCnt OBJECT-TYPE
SYNTAX Counter32
MAX-ACCESS read-only
STATUS current
Rev 002vx
1141780,
5 }
1 }
mm1ModemWaveform,
mm1ModemModCod,
Counter32,
Counter32,
Counter32,
Counter32,
Counter32,
Counter32,
Counter32,
Counter32
30 is the maximum size
1 }
2 }
