configuration variables and the querying of variables on the local
modem.
Fundamental operations:
> mm1ReadConfig
- Reads modem configuration variables from the modem and places them
into the SNMP agent monitor buffer.
> mm1InitEditBuffer
- Copies the monitor config buffer values into the edit config buffer
values.
the modem config values into the monitor config buffer.
> mm1ReadStatus
- Reads modem status variables from the modem and places them into
the SNMP agent monitor buffer.
> mm1ReadMetrics
- Reads modem metrics variables from the modem and places them into
the SNMP agent monitor buffer.
> mm1ReadDiagnostics
- Reads modem diagnostics variables from the modem and places them
into the SNMP agent monitor buffer.
> SNMP get operations
- Config variables: Data is read from the edit or monitor buffer
based on the mm1ConfigQueryType setting.
- Status/Metrics/Diagnostics variables: Data is read from the monitor
buffer.
> SNMP set operations
- All config set operations modify variables in the edit buffer.
- The mm1ReadConfig and mm1InitEditBuffer commands should first be
issued to pre-populate the edit buffer with the modem's current
configuration settings.
- The configuration variables desired to be modified should then be
updated through SNMP set commands.
> mm1CommitConfig
- Instructs the SNMP agent to load ALL edit buffer configuration
variables into the modem.
Incorrectly issuing any of the modem control commands will result in
the generation of an SNMP Notification negative acknowledgement.
faults, alarms, and events will each also result in the generation of
an SNMP notification message as specified by this MM1 Modem MIB."
REVISION "201211300000Z"
DESCRIPTION
"Initial release"
::= { products 6 }
comsatLabs
products
--
-- mm1 TOP Level MIB Structure
--
-- .1.3.6.1.4.1 (enterprises)
-- |
-- 3500 (comsatLabs)
-- |
-- 1 (products)
-- |
-- |-----> 6 (mm1)
--
--
--
--
7‐68
This should be executed after an mm1ReadConfig which reads
OBJECT IDENTIFIER ::= { enterprises 3500 }
OBJECT IDENTIFIER ::= { comsatLabs 1 }
|
|-----> mm1Control
|-----> mm1Config
|-----> mm1Status
