MEOLink User Manual
3.1.3 Transmit Mute
3.2 MEOLink Modem Web Interface
This section describes the MEOLink modem monitor and control data available through the
Web Interface.
3.2.1 Login
To login, do the following:
3.2.2 Navigation
The MEOLink Modem Web Interface is navigated through the use of tabs and tables within
the tabs. Each tab contains a dropdown selection to choose sub‐categories (see the
Configuration tab example below in Figure 18).
3.2.3 Load Config Button
The Load Config button loads all configuration changes made by the operator. The operator
can make changes on multiple tabs then click on the Load Config button (Figure 19) as a last
step. A confirmation message appears saying the load was "okay" (Figure 20).
Rev 002vx
1141780,

Switchovers will continue to occur whenever the active port goes down. Alarms
notify the operator when the active port goes down.

The modem transmission is off at power up and remains off until enabled by the
software.

The modem transmission is muted in the case of a fault.

The modem has a loopback mode where the transmission is muted and a
modulated IF signal is looped back to either or both demodulators.

Transmission is muted when the synthesizer is unlocked (e.g., when the reference is
switched).
1. Open a browser (IE8, Google Chrome, Opera, or Firefox)
2. Make sure cookies are enabled.
3. Enter the default or your login information. The default login is:
a. User: operator
b. Password: o3bo3b
Figure 18: Dropdown Selection
