MEOLink User Manual
mm1FpgaClockStatus OBJECT-TYPE
SYNTAX INTEGER { ool(0), locked(1) }
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"FPGA clock status for the corresponding fpgaClockStatusIndex."
::= { mm1FpgaClockStatusEntry
--
-- FPGA LVDS Receive Status Table
--
mm1FpgaLvdsRxStatusTable OBJECT-TYPE
SYNTAX SEQUENCE OF Mm1FpgaLvdsRxStatusEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"A table containing FPGA low voltage differential signaling (LVDS) receive
status information for each FPGA."
::= { mm1FpgaStatus
mm1FpgaLvdsRxStatusEntry OBJECT-TYPE
SYNTAX Mm1FpgaLvdsRxStatusEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing FPGA LVDS status for a specific FPGA."
INDEX { mm1FpgaLvdsRxStatusIndex }
::= { mm1FpgaLvdsRxStatusTable
Mm1FpgaLvdsRxStatusEntry ::= SEQUENCE {
mm1FpgaLvdsRxStatusIndex
mm1FpgaLvdsRxParityErrorCnt
mm1FpgaLvdsRxAlignmentStatus
}
mm1FpgaLvdsRxStatusIndex OBJECT-TYPE
SYNTAX INTEGER { host(1), tx1(2), tx2(3), rx1a(4), rx1b(5), rx2(6) }
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"FPGA LVDS receive status index."
::= { mm1FpgaLvdsRxStatusEntry
mm1FpgaLvdsRxParityErrorCnt OBJECT-TYPE
SYNTAX Counter32
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"FPGA LVDS receive parity error count for the corresponding
mm1FpgaLvdsStatusIndex."
::= { mm1FpgaLvdsRxStatusEntry
mm1FpgaLvdsRxAlignmentStatus OBJECT-TYPE
SYNTAX INTEGER { ool(0), locked(1) }
MAX-ACCESS read-only
STATUS current
DESCRIPTION
Rev 002vx
1141780,
2 }
2 }
1 }
INTEGER,
Counter32,
INTEGER
1 }
2 }
7‐99
