Chapter 2
Printer Component Locations
Printer Component Locations
Ribbon Spool
Ribbon Hub
Blue Tractor
Lock (2)
Barcode Sensor
Figure 4. Printer Component Locations
26
Barcode
Ribbon
Splined
Shaft
Date Code Label
Paper Support
Hammer Bank
Cover and
Tractor (2)
Ribbon Mask
Vertical
Position Knob
Platen Lever
Platen Stop
Ribbon Guide (2)
