Intervention Req
•
Send to Host (default). The printer sends a signal to the host
computer when the CANCEL key is pressed or a printer fault or
hold mode time-out occurs.
•
Do Not Send. No signal will be sent to the host computer.
Buffer Print
•
Disable (default). The printer will print normally.
•
Enable. The printer prints the EBCDIC data and control codes
received from the host as hex values. Refer to page 315 for
information on how to obtain a hex code printout.
Translation Tbl
Prints a table of the Coax interface's current character set. This
operation is valid only when the Coax interface is selected (see
"HOST INTERFACE" on page 85).

Column 132 Wrap

When enabled, this option causes the printer to line wrap at 132
characters despite the current print density, allowing more
characters per line. The options include:
•
Disable (default)
•
Enable

Usr Defined HTRN

This option is used in Twinax SPC emulation. The range is ASCII
character. This option allows users to define ther own lead-in
characters for the Printronix Specific commands. Select a hex
value for the following codes for the User Defined option:
•
Start Code 1 5F
•
Start Code 2 5F
•
Stop Code 5B
SPC Coax Params
203
