Primary Char. Set
You can select one of 92 pre-defined character sets by ID (although
character sets range from 0 - 109, not all sets are available on the
LJ500 printer), or you can select pitch, symbol set, and typeface
individually. If the combination you choose matches one of the 92
predefined sets, the ID submenu will reflect that selection. If not,
the ID menu will display
xx
does not match a pre-defined set. Set 0 is the default, and its
attributes are 10 cpi, Data Processing typeface, and Roman 8
symbol set.
Second Char. Set
Your printer can store an additional character set. To toggle
between them, send the Shift In (Decimal 15, to select the Primary
character set) or Shift Out (Decimal 14, to select the Secondary
character set).
Page Length Rep.
•
Inches/Page (default). All page length calculations are based
on the inches displayed on the panel.
•
Lines/Page. All changes in LPI or density will be changed
accordingly. The length of the page is the number of lines per
inch, or lpi.
For example, if the form in use is 82 lines at 6 lpi, the page is
physically 13.67 inches. Since 13.67 inches is not selectable
from the Length in Inches menu, change the representation to
lines, then set the number of lines to 82. The inches menu will
display 13.6 inches although the printer internally keeps the
exact form length of 13.67 inches.
Max Line Width
Set the maximum line width at 13.2 inches (the default) or 13.6
inches.
PCL-II Emulation
Epson FX Emulation
to indicate that the current character set
