Printronix P7000 User Manual page 50

Chapter 3
Integrated Print Management System
Spool
Right Hub
Figure 20. Loading the Barcoded Ribbon
5. Place the full spool on the right hand side ribbon hub and press
it into place.
IMPORTANT
The full spool has a barcode label on the bottom side and a
date code label on the top. Once the sensor reads and logs the
ribbon barcode, the Integrated Print Management System
starts to track ribbon usage. A date code label is on the top
side of the right hand spool.
If you remove the ribbon during the course of its life and want
to re-install the same ribbon, be sure to place the same spools
on the correct hubs.
50
Date Code Label
