Configuring Multicast VRFs
Step 8
Step 9
Step 10
Step 11
Step 12
Step 13
Step 14
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
172
Command or Action
interface interface-id
Example:
Device(config-vrf)# interface
gigabitethernet 1/0/2
ip vrf forwarding vrf-name
Example:
Device(config-if)# ip vrf forwarding
vpn1
ip address ip-address mask
Example:
Device(config-if)# ip address 10.1.5.1
255.255.255.0
ip pim sparse-dense mode
Example:
Device(config-if)# ip pim sparse-dense
mode
end
Example:
Device(config)# end
show ip vrf [brief | detail | interfaces]
[vrf-name]
Example:
Device# show ip vrf detail vpn1
copy running-config startup-config
Example:
Device# copy running-config
startup-config
Configuring IP Unicast Routing
Purpose
Specifies the Layer 3 interface to be associated
with the VRF, and enter interface configuration
mode. The interface can be a routed port or an
SVI.
Associates the VRF with the Layer 3 interface.
Configures IP address for the Layer 3 interface.
Enables PIM on the VRF-associated Layer 3
interface.
Returns to privileged EXEC mode.
Verifies the configuration. Displays information
about the configured VRFs.
(Optional) Saves your entries in the configuration
file.
