Multi-VRF CE Configuration Guidelines

Multi-VRF CE Configuration Guidelines
Note To use multi-VRF CE, you must have the Network Advantage license enabled on your switch.
• A switch with multi-VRF CE is shared by multiple customers, and each customer has its own routing
• Because customers use different VRF tables, the same IP addresses can be reused. Overlapped IP
• Multi-VRF CE lets multiple customers share the same physical link between the PE and the CE.
• Multi-VRF CE does not support all MPLS-VRF functionality. It does not support label exchange,
• For the PE router, there is no difference between using multi-VRF CE or using multiple CEs. In
• The switch supports configuring VRF by using physical ports, VLAN SVIs, or a combination of
• A customer can use multiple VLANs as long as they do not overlap with those of other customers.
• The switch supports one global network and up to 26 VRFs.
• Most routing protocols (BGP, OSPF, RIP, and static routing) can be used between the CE and the
• Multi-VRF CE does not affect the packet switching rate.
• VPN multicast is not supported.
• You can enable VRF on a private VLAN, and the reverse.
• You cannot enable VRF when policy-based routing (PBR) is enabled on an interface, and the reverse.
• You cannot enable VRF when Web Cache Communication Protocol (WCCP) is enabled on an
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
162
table.
addresses are allowed in different VPNs.
Trunk ports with multiple VLANs separate packets among customers. Each customer has its own
VLAN.
LDP adjacency, or labeled packets.
Figure 41-6, multiple virtual Layer 3 interfaces are connected to the multi-VRF CE device.
both. The SVIs can be connected through an access port or a trunk port.
A customer's VLANs are mapped to a specific routing table ID that is used to identify the appropriate
routing tables stored on the switch.
PE. However, we recommend using external BGP (EBGP) for these reasons:
◦ BGP does not require multiple algorithms to communicate with multiple CEs.
◦ BGP is designed for passing routing information between systems run by different
administrations.
◦ BGP makes it easy to pass attributes of the routes to the CE.
interface, and the reverse.
