Microscan MicroHAWK MV-20 Manual page 81

B
APPENDIX B
This section contains information about cables for the MicroHAWK MV-20,
MV-30, and MV-40 Smart Cameras.
Note: Cable specifications are published for information only. Microscan
does not guarantee the performance or quality of cables provided by
other suppliers.
Part Number
61-9000034-01 Cable, USB A to Micro B, 6 ft., MV-20
61-9000045-01 Cable, USB A to Micro B, 3 ft., MV-20
61-9000037-01 Cable, DB15 to Ext. Power/RS-232, MV-30
61-9000038-01 Cable, DB15 to Ext. Power/USB, MV-30
61-9000039-01 Cable, DB15 to Ext. Power/USB, I/O, MV-30
61-9000043-01 Cable, DB15 to BUS Power USB, MV-30
61-9000102-01 Cable, DB15 to USB/RS-232 Triggered, MV-30
61-9000054-01 Cable, M12 12-Pin Socket to 9-Pin Socket and M12 Plug
61-9000088-01 Cable, M12 12-Pin Socket to USB Keyboard Wedge and M12 Plug
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
Cable Specifications
Description
B
B-1
