Wiring for ON/OFF Illumination (NPN Only)
Warning: Contact between Pin 5 (gray wire) and any voltage source greater than 3.5VDC
will damage the illuminator.
Smart Series Illuminator
Connector
Smart Series Illuminator
Pin
Signal Name
1
+24VDC
2
Trigger –
3
DC Ground
4
Trigger +
5
Dim
* Insulate Pin 5 (gray wire)
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
MicroHAWK MV-40 External Illumination Control and Wiring
MicroHAWK MV-40
Connector A
MicroHAWK (Connector A)
Pin
to
2
to
7 and 12
Ground and Output Common
to
7 and 12
Ground and Output Common
to
2
to
6
Signal Name
Power
Power
Output 3
4
4-11
