Chapter 3
Getting Started with AutoVISION

Setting Up a Job in AutoVISION

AutoVISION is a critical component of the MicroHAWK's functionality. Designed for use
with the MicroHAWK, AutoVISION provides an intuitive interface, step-by-step
configuration, and a library of presets that allow easy setup and deployment. For more
complex vision applications, the system can be upgraded from AutoVISION to
Visionscape.
Item Part Number
1 7ABX-YZZZ-LPPP
2 97-000012-01
3 98-000103-02
4 61-000162-02
5 61-000160-03
6 99-000020-01
Note: Additional cables available in the Microscan Product Pricing Catalog.
1. Configure MicroHAWK Hardware
• Mount the camera as required by the application.
• Connect the Ethernet cable from "B" on the camera to the network.
• Connect the power supply to "3" on the QX-1.
• Connect the photo sensor to "T" on the QX-1.
• Connect the "Common" cable to "2" on the QX-1 and "A" on the camera.
• Plug in the power supply.
3-2
Description
MicroHAWK MV-20, MicroHAWK MV-30, or MicroHAWK MV-40
Power Supply, 100-240VAC, +24VDC, M12 12-Pin Socket
QX-1 Interface Device
Cordset, Common, M12 12-Pin Socket (Screw-On) to M12 12-Pin Plug
Cordset, Host, Ethernet, M12 8-Pin Plug (Screw-On) to RJ45, 1 m.
Photo Sensor, M12 4-Pin Plug, NPN, Dark Off, 2 m.
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
