Appendix B
Cable Specifications
MV-20 Cables
61-9000034-01/61-9000045-01 USB Type A-to-Micro B Cable
The 61-9000034-01/61-9000045-01 Micro-USB Type B plug to USB Type A plug cable is a
double-ended shielded ferrite core USB cable. 61-9000034-01 is 6 feet long, and 61-9000045-01
is 3 feet long. This cable is used for basic communications-only applications.
Micro-USB
Type B
Plug
B-2
Shown with optional ferrite
core (98-9000035-01, Ferrite
Core Snap-On Kit for USB
Cable – required for Class B
Emissions)
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
USB
Type A
Plug
