Chapter 2
System Components

Hardware Components and Accessories

The table below lists MicroHAWK Smart Camera hardware components and the table on
the next page lists the accessories. The reference numbers shown on configuration drawings
later in this section refer to these tables.
Item Part Number
1 7ABX-YZZZ-LPPP
2 61-9000034-01
3 61-9000045-01
4 61-9000043-01
5 98-9000048-01
6 97-9000006-01
7 61-9000037-01
8 98-9000049-01
9 61-9000038-01
10 98-9000050-01
11 97-000011-02
12 61-9000039-01
13 97-000012-02
14 99-000018-01
15 FIS-0001-0035G
16 61-3000026-03
17 99-000019-01
18 61-9000102-01
19 97-000012-01
20 98-000103-02
21 61-000162-02
22 61-000160-03
23 99-000020-01
24 99-000020-02
25 61-9000054-01
26 61-9000088-01
Upgrade to Visionscape
98-000217-01
Mounting Options
98-9000034-01
Documentation
37-000010-01
2-2
Description
MicroHAWK MV-20, MicroHAWK MV-30, or MicroHAWK MV-40
Cable, USB A to Micro B, 6 ft., MV-20
Cable, USB A to Micro B, 3 ft., MV-20
Cable, DB15 to BUS Power USB Type A, MV-30
Kit, Cable, DB15 to Ext. Power/RS-232 with Power Supply, MV-30 – includes
97-9000006-01 and 61-9000037-01
Power Supply, 5V – for use with cables 61-9000037-01 and 61-9000038-01
Cable, DB15 to Ext. Power/RS-232, MV-30
Kit, Cable, DB15 to Ext. Power/USB with Power Supply, MV-30 – includes
97-9000006-01 and 61-9000038-01
Cable, DB15 to Ext. Power/USB, MV-30
Kit, Cable, DB15 to Ext. Power/USB, I/O with Power Supply, MV-30 – includes
97-000011-02 and 61-9000039-01
Power Supply, 100-240VAC, +5VDC, 2-Pin U.S./Euro Plug
Cable, DB15 to Ext. Power/USB, I/O, MV-30
Power Supply, 100-240VAC, +24VDC, TRK 3-Pin, U.S./Euro Plug
IB-131 Interface Box
Converter, IC-332, 24V/5V, Opto I/O – for use with IB-131
Cable, Communication, DB25 Plug to DB9 Socket, 6 ft.
Photo Sensor, Visible, NPN, Light On, 5VDC
Cable, DB15 to USB/RS-232, Triggered, MV-30
Power Supply, 100-240VAC, +24VDC, M12 12-Pin Socket
QX-1 Interface Device
Cordset, Common, M12 12-Pin Socket (Screw-On) to M12 12-Pin Plug
Cordset, Host, Ethernet, M12 8-Pin Plug (Screw-On) to RJ45, 1 m.
Photo Sensor, M12 4-Pin Plug, NPN, Dark Off, 2 m.
Photo Sensor, M12 4-Pin Plug, NPN, Dark On, 2 m.
Cable, M12 12-Pin Socket to 9-Pin Socket and M12 Plug
Cable, M12 12-Pin Socket to USB Keyboard Wedge and M12 Plug
Upgrade from AutoVISION to full Visionscape functionality
MicroHAWK MV-20-to-MINI Hawk Adapter Plate Kit
Microscan Tools Drive (Software, documentation, links to Microscan website)
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
