Appendix C

General Specifications

MV-40 General Specifications
MV-40 Dimensions, Enclosure
Dimensions
Height: 25 mm (0.98")
Width: 45 mm (1.77")
Length: 45 mm (1.77")
Weight: 68 g (2.40 oz.)
MV-40 Environmental, Emissions
Operating Temperature
0° to 45° C
(32° to 113° F)
MV-40 Electrical
Electrical
4.75-30 VDC, 200 mV p-p max ripple, 150 mA at 24 VDC (typ.)
MV-40 Connector, Communication, Discrete I/O, Illumination, Indicators
Connector Passive PoE Comm.
24 V Passive
M12 12-Pin
Power over
Power,
Ethernet, Type
B; Requires
M12 8-Pin
passive PoE
Ethernet
power supply
MV-40 Speed, Memory, Software, FTP Image Storage
Speed Memory
2 GB Non-Volatile Flash,
800 MHz
256 MB RAM
MV-40 Sensor Options, Shutter, Exposure Time, Frames per Second
Sensor Options
WVGA (Mono): CMOS 0.34 MP (752 x 480),
4.51 x 2.88 mm, 6 μm pixel size
SXGA (Mono): CMOS 1.2 MP (1280 x 960),
4.80 x 3.60 mm, 3.75 μm pixel size
QSXGA (Color): CMOS 5 MP (2592 x 1944),
4.536 x 3.402 mm, 1.75 μm pixel size
MV-40 Optics, Focus
Optics
Fixed: Standard Density (5.2 mm); High Density (8.0 mm);
Ultra-High Density (16.0 mm)
Autofocus: Standard Density (5.2 mm); High Density (7.7 mm);
Ultra-High Density (16.0 mm)
C-4
Storage Temperature
-50° to 75° C
(-58° to 167° F)
Discrete I/O
2 in/3 out: Optoisolated
Trigger Input; New Master
RS-232, Input: Bi-directional,
Ethernet Optoisolated, 1-28 V-rated
TCP/IP, (10 mA @ 28 VDC); Strobe
EtherNet/IP, Output, 2 General Purpose
PROFINET Outputs: Bi-directional,
I/O Optoisolated, 1-28 V-rated
(I < 100 mA @ 24 VDC,
CE
current limited by user)
Software
AutoVISION Sensor, AutoVISION, Visionscape
Shutter
Global
Rolling
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
Enclosure
IP65/67, Aluminum
Humidity
5% to 95%
(non-condensing)
Illumination
Inner Red: 4 LEDs, 625 nm
nominal
Inner White: 4 LEDs
Outer Red, White, Blue, or IR:
8 LEDs
Light Modes: Inner or Outer; Off,
On, Strobe, Power Strobe; Power
Strobe for Outer LEDs only
Operating Life: 50,000 hours @
25° C
Exposure Time
WVGA: 50 to 66,667 μs
SXGA: 66 to 58,825 μs
QSXGA: 66 to 66,667 μs
Focus
Fixed: Factory set to 50, 102, 190, or 300 mm (SD, HD);
64 or 400 mm (UHD)
Autofocus: Software-adjustable 50 to 300 mm (SD, HD);
40 to 150 mm (UHD)
Emissions
EN 55022:2010 Class A Limits
Indicators
TRIG, PASS,
FAIL, MODE,
LINK, PWR LEDs,
2 Target Pattern
LEDs, 2
Inspection Passed
(Green Flash)
LEDs
FTP Image Storage
Supported
Frames per Second
WVGA: Up to 52
SXGA: Up to 40
QSXGA: Up to 5
