Microscan MicroHAWK MV-20 Manual page 65

MV-30 and MV-40 Fixed Focus
MV-30/40 FOV Chart
Camera-to-Part
Distance
(mm) (inch)
50
64
102
WVGA
190
300 11.81
400 15.75
50
64
102
SXGA
190
300 11.81
400 15.75
50
64
102
QSXGA
190
300 11.81
400 15.75
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
SD - FOV (mm)
Width Height
1.97 49 32
2.52 62 39
4.02 95 60
7.48 171 109
266 170
353 225
1.97 53 39
2.52 66 49
4.02 101 75
7.48 182 136
283 213
376 282
1.97 50 37
2.52 63 47
4.02 96 72
7.48 174 130
271 202
359 268
Fixed Focus Lens Type
HD - FOV (mm)
Width Height
34 22
43 27
66 42
118 76
185 118
245 156
36 27
45 34
70 52
126 95
196 147
260 195
35 26
43 32
67 50
121 90
188 140
249 186
Optics
UHD - FOV (mm)
Width Height
15 10
19 12
30 19
54 34
83 53
111 71
16 12
21 15
32 24
57 43
89 67
118 88
16 12
20 15
30 22
54 41
85 63
113 84
