Chapter 1
Introduction

MicroHAWK MV Part Number Structure

MicroHAWK MV part numbers follow the format 7ABX-YZZZ-LPPP.
7 = MicroHAWK.
Example Part Number: 7422-3000-2004
Description: MicroHAWK MV-40, IP65 Case, 24V, Ethernet, Machine Vision, SXGA, 1.2 Megapixel,
Mono, Ultra-High Density, Autofocus, White Outer LEDs, AutoVISION + Verification + Visionscape.
(A) Model
1: Engine, No Case, USB
2: MV-20, IP40 Case, USB
3: MV-30, IP54 Case, 5V, USB
4: MV-40, IP65 Case, 24V, Ethernet
(B) Application Type
2: Machine Vision
(X) Sensor
1: WVGA 0.3 Megapixel, Mono
2: SXGA, 1.2 Megapixel, Mono
3: QSXGA, 5 Megapixel, Color
(Y) Optics
0: Custom
1: Standard Density – 5 mm Focal Length
2: High Density – 8 mm Focal Length
3: Ultra-High Density / Long Range – 16 mm Focal Length
(ZZZ) Focal Distance
000: Autofocus
050: 50 mm = 1.96 in.
102: 102 mm = 4.02 in.
190: 190 mm = 7.48 in.
300: 300 mm = 11.81 in.
(L) Illumination
0: Inner LEDs Only
1: Red Outer LEDs
2: White Outer LEDs
(PPP) Software
000: AutoVISION Sensor
001: AutoVISION
002: AutoVISION + Verification
003: AutoVISION + Visionscape
004: AutoVISION + Verification + Visionscape
Notes:
• (A) Model: The MicroHAWK Engine is available for OEM-certified partners only.
• (L) Illumination: Outer LEDs provide extra illumination. Base-level LED illumination included with all cameras.
• Field Upgrades: Not available for optics or illumination due to factory settings for optical alignment,
LED balancing, and sealing for IP enclosure rating. However, the camera's software is field-upgradeable
via licenses.
1-6 MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
