Appendix
A
Connector Pinouts
MV-20 Connector
Micro-USB Type B Socket
Pin
Function
1
Vbus (5V)
2
D–
3
D+
4
NC
5
Ground
A-2
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
