4. Operation of UMX-OPT-TX150R
UMX-OPT-TX150R uses some of the standard timings for the RS-232
control and pass-through mode. To work the bidirectional serial
communication well between serial ending devices users must
choose the proper baud rate on the transmitter units. Please read
the serial devices' user's manual to find the appropriate baud rates.
The best one is both devices' most common value.
If the communication speed ability of a serial device is unknown use
the lowest (#1: 9600) value.
Available BAUD RATE rotary values:
Rotary switch position
#0
#1
#2
#3
#4
#5
#6
#7
#8
#9
INFO: When all the front panel LEDs are blinking, they refers to the
undefined baud rate settings (baud rotary switch is set from #5 to #9).
DVI-D DVI-D
DVI-A Audio1
VGA Audio2
HDMI HDMI
VIDEO AUDIO
BAUD rate
Software set (57600 default)
9600
19200
38400
57600
The system consists of the following: a Blu-Ray player and a laptop
Not used
as sources, a programmable touch panel as a controller, then a
Not used
Lightware UMX-OPT-TX150R and HDMI-3D-OPT-RX150R as the optical
Not used extenders, then a projector as a sink device. The touch panel has three
buttons. The desired functions of the buttons are that they can power
RS232=Pass / Control
on and off the projector, and switch between the inputs. Let's examine
KVM (under development)
the detailed solution.
Three types of the touch panel's commands:
HDCP
Autoselect
LINK
S/PDIF
Initializing:
First of all the touch panel can control the projector only if RS-232
settings are the same for the touch panel and the projector.
Commands:
(set_RS-232)
UMX-OPT-TX150R – User's Manual
Detailed Example
Laptop
VGA
DVI-I IN
HDMI
Blu-Ray player
( ): settings of the touch panel / not sent /
[ ]: command to the projector / sent via RS-232 to UMX-OPT-
TX150R then via fiber optical cable to the projector /
{ }: command to the UMX-OPT-TX150R / sent via RS-232 to
UMX-OPT-TX150R /
Comments:
/* Set the appropriate RS-232 settings which are
fit to the UMX-OPT-TX150R and the projector as
well. */
INFO: 57600, 38400, 19200 or 9600 Baud, 8 bit, 1stop bit, no parity.
These settings are fit to the UMX-OPT-TX150R.
Touch panel
RS-232
Fiber cable
DVI-D DVI-D HDCP
DVI-A Audio 1 Autoselect
VGA Audio 2 LINK
HDMI HDMI S/PDIF
VIDEO AUDIO VIDEO AUDIO POWER
VGA IN AUDIO 1 AUDIO 2 HDMI IN S/PDIF IN INPUT STATUS SELECT SELECT
UMX-OPT-TX150R HDMI-3D-OPT
Button 1 (Power on the projector):
The touch panel can control the projector only if the UMX-OPT-TX150R
is in pass-through mode.
Commands:
{RS232=PASS}
[projector_on]
Button 2 (Select the HDMI input):
The touch panel can only control the UMX-OPT-TX150R if that is in
control mode.
Commands:
{RS232=CONTROL}
{4@1 AV}
Button 3 (Power off the projector):
The touch panel can control the projector only if the UMX-OPT-TX150R
is in pass-through mode.
Commands:
{RS232=PASS}
[projector_off]
