XIII. OCATING AN
The AirCheck G2 can use either the three internal antennas
or the optional external antenna (sold separately) to locate
devices. In areas that have many rooms, for example in
schools and hospitals, use the internal antennas to locate.
In large, open areas, the optional external antenna can help
you locate devices more quickly.
Directional Antenna," page 70.
The AirCheck G2 Tester can use either the external antenna
or the internal antennas, but not both at the same time.
When you are on the Locate screen, if AirCheck G2 has
sensed NETSCOUT's external antenna being connected, the
switch is set to the external antenna. (Otherwise, touch the
antenna button .) When the external antenna port is
turned off, AirCheck G2 automatically switches to the internal
antenna. Otherwise, the Locate function defaults to the
internal antenna.

How to: Locate an AP, Client, or Interferer

1 To locate an access point: Go to the Access Points list
screen, and select the access point you want to locate to
open the Access Point Details screen
To locate a client: From the Home Screen, touch Clients,
and select the client you want to locate to open the
Client Details screen
A P
CCESS OINT
See "Using the External
(Figure 9).
(Figure 15).
, C ,
LIENT OR
To locate an interferer: From the Home Screen, touch
Interferers. You can begin locating from either the
Interferer Events screen or the Interferer Event Details
screen (Figure
2 Press Locate. 
Figure 46
Figure 47
Figure 49
3 Divide the area you want to search into four sections, as
shown in
4 Make a note of the signal strength.
5 Go to the other three corners of the area, and make a
note of the signal strength at each corner.
6 Go to the section that has the strongest signal.
7 Repeat steps 3, 4, 5, and 6 again until you find the device.
NOTES:
If you do not find the device, look on the floor above or

below you.
If you cannot find a client, and the device shows a

connection to the network, first find the access point that
the device used, then look for the device.
64

Locating an Access Point, Client, or Interferer

I
NTERFERER
17).
shows the Locate Access Point screen. 
shows the Locate Client screen.
shows the Locate Interferer screen.
Figure 45. Go to one corner of the area.
