Network Quality Results

Figure 24. AutoTest Network Quality
Network Coverage: Indicates the number of access points
the Tester detected that are supporting the network. This
field also displays a rating symbol based on the Network
Coverage threshold.
Co-channel Interference: Displays the number of APs that
exceed the minimum signal strength threshold with primary
or secondary channels on the same channel on which the
Tester connects to the network.
Security: Indicates whether all access points use security
protocols that are more secure than WEP, for example, WPA
or WPA2.
Using AutoTest to Diagnose Your Network Health

Connection Test Results

The Connection test results indicate whether or not you can
connect to an AP for the configured network at your current
location. The Connection field turns
was successful and red
Touch the down arrow
high level connection diagnostics. These results also receive a
rating based on whether the individual test was successful, or
based on how measurements compare to the configured
thresholds: Pass or Success (green),
or Fail (red)
Connect to AP: Indicates whether the Tester was able to
connect to the AP.
Authenticate: Indicates whether the Tester was able to
authenticate with the AP.
Exchange packets with AP: Indicates whether the Tester
received packets back from the AP.
41
green if the connection
if the connect was unsuccessful.
to the right of Connection to view
Warning (yellow), 
