7.6.4

Port Forwarding

The Port Forwarding window is used to set up servers and services on local LAN machines. The picture below shows
how you can set up a rule that would allow a website that is being hosted on 192.168.1.109, to be reached from the
outside by entering http://routersExternalIp:12345/
Field Name
1. Name
2. Protocol
3. External Port
4. Internal IP address
5. Internal port
Teltonika Solutions
Possible values
New rule's name
TCP/UDP/TCP+UDP/Other
1800 or 2000-2200
IP address of some device on your
LAN
1800 or 2000-2200
Explanation
Name of the rule, used purely to make rule
management easier
Type of protocol of incoming packet
From this port on the WAN network the traffic will be
forwarded
The IP address of the internal machine that hosts
some service that we want to access from the outside
The rule will redirect the traffic to this port on the
internal machine
