RUT955 LEDs
Main Page > RUT Routers
This chapter provides explanations for LED actions on a RUT955 router. The information applies for
both Quectel and MeigLink modules used in Teltonika devices.
Contents
1 Power LED
2 Ethernet port LEDs
3 Connection status LED
4 Signal strength LEDs
Power LED
The power LED is located on the bottom left corner of the front panel, just under the power
connector:
It can perform two different actions:
ACTION
LED turned ON
LED turned OFF
Ethernet port LEDs
The Ethernet port LEDs are located on the router's front panel, under each respective Ethernet
port:
They represent activity happening on the router's Ethernet ports:
ACTION
LED turned ON
LED turned OFF
LED blinking
LEDs light up and turn OFF in sequence from WAN port to LAN1 port
* The bootloader menu is a special router state from which certain upgrades can be performed.
For more information on the bootloader menu, click
> RUT955 > RUT955 Manual > RUT955 LEDs
DESCRIPTION
Router is powered up
Router is not powered up
DESCRIPTION
Operating as a 10/100 Mbps connection
No link established
Connection established and there is activity on this port (data being transferred)
The router is in the bootloader menu
here
state*
