USER'S MANUAL. TV EXPLORER II/II+
Whenever a DiSEqC program is sent, the commands that correspond to the
equipment status in relation to the Horizontal or Vertical polarization and High or Low
frequency band are also sent. This allows assuring that the installation status is the one
indicated by the equipment.
The COMMANDS option from DiSEqC menu allows to execute any of the
following commands:
CHARACTER
General
Non-assigned Switch
Assigned Switch
Positioner
When selecting the COMMANDS option in the Spectrum Analyser mode
[13] in the screen will appear a dynamic execution line in order to use with the
positioner commands: DRIVE EAST / WEST. This allows to carry out a fine adjustment
in steps or in seconds to aim the antenna through the rotary selector [1].
70
60
50
40
DRIVE EAST (STEPS)
CH:
09/2009
COMMAND
POWER
RESET
STANDBY
SAT A/B
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 4
POSITION A/B
SWITCH OPTION A/B
DISABLE LIMITS
ENABLE LIMITS
LIMIT EAST
LIMIT WEST
DRIVE EAST SEC.
DRIVE EAST STEPS
DRIVE WEST SEC.
DRIVE WEST STEPS
GOTO POSITION
HALT
STORE POSITION
RECALCULATE
Table 5.- Available DiSEqC commands.
FREQ.:
POWER:
12108.1
Figure 65.- DiSEqC commands: DRIVE
ASSOCIATED PARAMETER
---
---
---
A / B
A / B
A / B
A / B
A / B
A / B
A / B
---
---
---
---
1 to 127
1 to 127
1 to 127
1 to 127
1 to 255
---
1 to 255
1 to 255
1508.80 MHz
64.4 dB
5
SPAN: 200 MHz
