Promax TV EXPLORER II User Manual page 192

-10
-20
-30
DELAY:
COMPLETE
To navigate between the detected echoes:
1. Place the cursor
2. Press the rotary knob. Then, the vertical cursor will placed on the first echo
(Figure 58.-).
3. Once the cursor is on the first echo, you should see at the bottom of the
screen the delay and distance measurements of the echo with regard to the
carrier.
4. Press the rotary knob again to switch to the next echo.
-10
-20
-30
DELAY:
COMPLETE
Page 80
0
0.0
Figura 57.- ECHOES found.
[6] on the menu option "FIND ECHO".
0
46.5
Figura 58.- ECHOES analysis.
USER'S MANUAL. TV EXPLORER II/II+
us 0.0 km
FIND ECHO
us 13.9 km
FIND ECHO
ZOOM: x1
RUN
ZOOM: x1
RUN
09/2009
