When trying an option by means of the rotary selector [1] it appears a menu that
contains the names of the stored files. Select one using the rotary selector [1] or press
EXIT.
The saved spectrum, constellation and MER by carrier data can be exported in the
form of a text file (CSV). These files can be very useful if they are included in documents
such as a spreadsheet, data base, etc. There is a software application to download the
files to the PC.
Users can also develop a tailored program to read those files using remote control
commands.

5.19.2 Delete capture

Also it is possible to delete the stored screens. For it, accede to the Utilities menu
[22] and after activating this function, select one of the following options according to
the model and type of capture that has been done:
1. constell/
2. mer/
3. sp/
When pressing with the rotary selector [1] over the option will appear a menu that
contains the names of the stored files. Select one by means of the rotary selector [1] or
press EXIT.
5.20

PRINT SCREEN function (only TV EXPLORER II+)

It is also possible to save anything that appears on the screen of the meter using
the "PRINT SCREEN" function. To save an image you only need to press the key
[10] during a few seconds. A file with the screen content in bit map format (bmp) will
be generated automatically. These files can be viewed later on using any program that
supports .bmp formats.
Note: There are three cases where this function can not be used.
Analogue and digital video pictures, configuration menus and OSD messages.
Page 82
Deletes a constellation diagram.
Deletes a MER by carrier graph.
Deletes a frequency spectrum.
USER'S MANUAL. TV EXPLORER II/II+
09/2009
