USER'S MANUAL. TV EXPLORER II/II+
5.21

TV Operating Mode

When pressing the
/ II+ accedes to the TV mode, and tries to demodules on the monitor the currently video
signal on tune.
In the monitor will appear the TV picture with a window on the lower part to show,
for five seconds whenever the signal is analogue; the channel number, the frequency,
the active channel set, the colour system and the TV standard.
CHANNEL:
CCIR
FR:
NOTE:
The symbol
instrument has detected a saturation condition for analogue signals in
the currently channel on tune.
This symbol also appears, when the colour subcarrier signal (Burst)
does not contain information and therefore the images are shown in black
and white.
If it is a digital television signal (DTV) on screen appears, for about some seconds,
the following parameters: channel number or satellite name, frequency, active channel
plan and satellite downlink frequency. The following data box shows the video data: type
of video coding (MPEG-2 or MPEG-4), video bit rate, video program identifier (VPID)
and the TS identifier (TSID). One other data box contains audio information: type of
audio coding (MPEG-1, MPEG-2 or AC-3), audio bit rate, audio program identifier (APID)
and language (e.g. spa). The last box located in the same column shows the network
data: network name and/or satellite orbital position, service name, netwok identifier (NID)
and service identifier (SID).
09/2009
[10] key from any mode of operation the TV EXPLORER II
S10
168.25 MHz
Figure 59.- Analogue channel monitoring.
in the upper corner of the screen indicates that the
50 Hz
PAL BG
Page 83
