In frequency tuning mode there are two ways of tuning:
1. Turning the rotary selector [1].
Turning the rotary selector [1] selects the desired frequency (tuning is
continuous from 5 to 1000 MHz and from 950 to 2150 MHz). When turning it
clockwise frequency increases while turning it anticlockwise frequency
decreases.
2. Using the keyboard.
Press the rotary selector [1] (the frequency listing will disappear and will
appear on the upper left corner of screen the keyboard symbol of manual data
entry
keyboard. The TV EXPLORER II / II+ will calculate the tuneable frequency
closest to the entered value and then display it on-screen.
5.5

Automatic Transmission Search

Holding pressed the
tuning a channel the instrument tryes to identify it and save it with the configuration. If
the identification is not possible the channel is removed from list. As a result obtains a
new channel plan that only contains the channels that have been identified.
5.6

Selecting the measurement configuration: Analogue/ Digital signal

Measuring the characteristics of a channel depends, in the first place, on the type
of modulation: analogue or digital.
Use key
[17] key to show the measurements CONFIGURATION menu and select the Signal
option by turning and pressing the rotary selector [1]. The Signal option allows setting
the type of signal
TV EXPLORER II / II+ activates the last measurement configuration used for that type of
signal.
Page 32
), next enter the frequency value in MHz using the numeric
[25] key search starts over the active channel plan. When
[17] to switch between analogue and digital channels. Press the
to measure.
USER'S MANUAL. TV EXPLORER II/II+
When switching to a new type,
09/2009
the
