This option is very useful if we want to work during the capture process due to
the problems can be detected in real time and the cursor can be moved at any
temporal reference. When a temporal movement is introduced, noticed that a
negative sing is placed before the number by default. This is due to the
displayed data on the screen is captured in real time so that if we want to
analyze a previous point we should go backward in the time. For example if
the elapsed time is 500 s and we want to go to the second 200, the temporal
position t must be filled with — 300s.
Save
Introduce a name to save the file. If the name already exists a message will be
showed and the file could be overwritten or the operation canceled
Acquisition mode
Select the different modes to capture a file,
CIRCULAR:
If this option is selected, other menu will be displayed, Choose the file
duration. The capture system stores the data in a file during the
performed period of time. When the elapsed time is higher than the
file, the last captured data will be stored. For example, if the selected
file time is 1800s and the elapsed time is 36000, the file will be stored
the seconds from 34200 to 36000.
BOUNDED:
If this option is selected, other menu will be displayed. Choose the file
duration. When the end of the file arrives, the capture will be stopped
and stored.
CONTINUOUS:
The equipment starts the capture and it is not stopped until the user
does it manually or the equipment does not have free memory.
OSD info
If this option is selected, on the left edge of the screen a heading to connect each
signal level (dB) with the respective colour will be showed.
Start
Select it to start the capture process.
To finalize the capture manually pres the key
09/2009
[17]and select STOP.
