USER'S MANUAL. TV EXPLORER II/II+
Figure 6.- Connecting external attenuator on RF input [30].
ATTENTION
Note the importance to protect the RF
accessory to block the AC voltages used in CATV cables (needed to feed the
amplifiers) and remote control.
34
[31] RESET button
Enables the user to restart the instrument if there is any irregularity when
operating.
09/2009
35 36
Figure 7.- Lateral panel elements.
[30] input signal with an
31 32 33
