Configuration and Operation
·
To stop running a Pattern or Sequence path, move the cursor to the Live View pane and move the
camera in any direction.
·
The PT Speed setting controls the rate at which the pan and tilt changes. Set a number between 1
and 10 as the PT Speed every time users pan or tilt the camera via the PT control panel.
·
Live View Pane Pan/Tilt Control
Control pan/tilt by left-clicking the cursor in the Live View pane and dragging the pointer in any
direction. Placing the pointer close to the center of the image results in a slow rate of change.
Placing the pointer further from the center results in a more rapid rate of change.
Fullscreen
Mode
Click this button to view the monitored image in full screen mode when using Digital Zoom Control. Use the
mouse to control zoom effects in Full Screen mode: scroll the mouse wheel (for zoom in/out), and drag the
mouse into any direction. Double-click on the screen to exit Full Screen mode and return to the Home
page.
9.3

System Tab

The Settings tab in the Navigation Bar opens the sections in the sidebar that are used for configuring the
camera. It opens on the System section, which includes the following tabs:
34
PT Speed Drop-Down Menu
System Section Tabs
CP-6302 User and Installation Guide
September 7, 2017
