FLIR Quasar Gen III User And Installation Manual page 30

Configuring Communication Settings
7. Right-click the camera whose network property is to be changed. From the context menu that
opens, select Assign IP. The Assign IP dialog is displayed.
Tip:
Record the camera's MAC address for future reference.
8. To access DNA, do one of the following:
a. For DHCP (not supported by Latitude):
i. Select Use DHCP. Do not use for Latitude.
ii. Click Update and wait for status.
b. For Static IP (recommended for Latitude users):
i. Do not select the Use DHCP checkbox. This is recommended for security purposes
and for and Latitude users. In the IP Address, Gateway, and Netmask, enter the
respective LAN/VLAN (optional DNS) values.
ii. Click Update and wait for
24
DNA Assign IP – Use DHCP Dialog Box
DNA Assign IP – Static IP Dialog Box
OK status to be displayed.
CP-6302 User and Installation Guide
September 7, 2017
