Configuration and Operation
9.7.4

Sequence

The Sequence page enables you to define up to eight Sequence lines for the camera image. A Sequence
line is an automated series of camera movements from one Preset Point to another, in a pre-determined
order, and for configurable time periods. Each Sequence line can contain up to 64 different Preset Points.
Note:
Before creating a sequence, you must first define at least two Preset Points. See Preset.
To set up Sequence Line
1. In the Sequence setting section, click EDIT. The Sequence Set screen opens.
2. Select a Sequence line number from the Sequence line drop-down list.
3. Define each Preset Point for the Sequence line in the desired order:
a. Select the first Preset Point from the Preset Name list. Use the PrePage or NextPage buttons
to navigate between the Sequence preset numbers.
b. Specify the Dwell time (between 0 and 127 seconds) for the first Preset Point.
c. Specify the camera's Speed (between 0 and 14).
4. Repeat steps a, b, and c for up to 64 Preset Points.
5. Click SAVE to save your preset sequence.
112
Sequence Screen
Sequence Set Screen
